Feature
● 64 / 128 Test Point Architecture: Rapidly scans complex multi-pin connectors, row line cables, and automotive wiring harnesses for high-throughput QA.
● Self-Learning Harness Entry: Eliminates tedious manual pin mapping; automatically reads and stores conduction data from a master wire sample in seconds.
● 4-in-1 Fault & Intermittent Swing Test: Detects opens, shorts, misaligned pins, and instant/transient open and short circuits while flexing the harness under test.
● Integrated Point-Finding Probe: Dedicated probe pen allows technicians to identify test points, isolate pinouts, and troubleshoot test fixtures effortlessly.
● Multi-Prompt OK/NG Feedback System: Combines an LCD screen, dual indicator lights, adjustable alarm tones, and clear voice prompts to guide operators instantly.
Application Range
● Automotive & Vehicle Wiring Harnesses: Comprehensive continuity and mis-wiring verification for engine looms, door harnesses, lighting lines, and dashboard assemblies.
● Flat Ribbon & Row Line Cables: High-speed pin-to-pin continuity and dislocation testing for IDC flat cables, FFC lines, and multi-conductor jumpers.
● Dynamic & Flex Cable Assemblies: Intermittent short/open circuit detection during mechanical flex or swing testing for robotics, industrial machinery, and vehicle leads.
● Fixture Calibration & QA Testing: Fast pin identification and fixture wiring verification using the integrated point-finding probe pen.
Feature ● Wire cutting, single (or double) end stripping, single (or double) end crimping, single end insertion of heat-shrink tub and heating, single end sleeve inserting machine ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Functions: Wire cutting, single/double-ended stripping, single/double/parallel-ended crimping, single/double/parallel heat-shrink tubing application. ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Equipped with high-precision servo motors for cutting and stripping mechanisms, the system delivers exceptional accuracy and consistency in wire processing operations. The positive and negative screw structure cutting blade ensures precise stripping results, while the robust ductile iron crimping mechanism provides stable crimping height and superior rigidity for reliable terminal connections. ● Featuring an intuitive color touchscreen interface with comprehensive program memory functions, the machine enables rapid product changeover through one-key parameter recall. The modular design allows individual function modules to be activated or deactivated as needed, maximizing production flexibility and equipment utilization across different product lines and manufacturing requirements.
Feature ● Maximum Rubber Sleeve Size: Diameter 30mm, Thickness 20mm, Square 30*30*20mm. ● Production Efficiency: Average 5 seconds/hole, slight differences may occur due to thread length and plastic shell positioning. ● Needle assembly changeover: 3 minutes; tube assembly changeover: 3 minutes; claw assembly changeover: 9 minutes. ● High production efficiency, saving 2-5 people and reducing manual labor intensity. ● High equipment compatibility; can achieve threading of various rubber sleeves through changeover, changeover time 15 minutes. ● High safety performance; multi-step, two-hand start-up. ● One-button switching between single and two rubber sleeve functions (customizable).
