Feature
● Integrated Heat Shrink Tube Processing
Automatically feeds, cuts, applies, and heat shrinks tubing in one continuous production process, eliminating manual tube handling.
● Designed for 4-Core Wire Harnesses
Built for multi-core wire harness production, combining tail processing and riveting with insulated heat shrink protection.
● PLC Touchscreen Control
The PLC-based touchscreen interface provides simple parameter adjustment and stable operation during continuous production.
● Higher Production Efficiency
Processes approximately 750–950 pieces per hour, helping reduce manual labor while improving production consistency.
● Customizable Tooling
Tooling can be customized according to different heat shrink tube sizes and wire harness specifications for flexible production.
Application Range
The EW-7095 is designed for manufacturers requiring automatic riveting and heat shrink tube processing for multi-core wire harnesses within a single production workflow.
● Automotive Wire Harness Manufacturing: Applies heat shrink protection to multi-core harnesses used in vehicle electrical systems.
● Industrial Equipment Assembly: Processes control cables and equipment wiring that require insulated heat shrink protection after riveting.
● Consumer Appliance Production: Suitable for power cords and appliance wiring that require durable insulated wire terminations.
● Communication Cable Processing: Handles multi-core communication cables with automatic tube application and heat shrinking.
● OEM Wire Harness Production: Customized tooling supports different heat shrink tube sizes and customer-specific wire harness configurations.
Feature ● Wire cutting, single (or double) end stripping, single (or double) end crimping, single end insertion of heat-shrink tub and heating, single end sleeve inserting machine ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Functions: Wire cutting, single/double-ended stripping, single/double/parallel-ended crimping, single/double/parallel heat-shrink tubing application. ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Equipped with high-precision servo motors for cutting and stripping mechanisms, the system delivers exceptional accuracy and consistency in wire processing operations. The positive and negative screw structure cutting blade ensures precise stripping results, while the robust ductile iron crimping mechanism provides stable crimping height and superior rigidity for reliable terminal connections. ● Featuring an intuitive color touchscreen interface with comprehensive program memory functions, the machine enables rapid product changeover through one-key parameter recall. The modular design allows individual function modules to be activated or deactivated as needed, maximizing production flexibility and equipment utilization across different product lines and manufacturing requirements.
Feature ● Maximum Rubber Sleeve Size: Diameter 30mm, Thickness 20mm, Square 30*30*20mm. ● Production Efficiency: Average 5 seconds/hole, slight differences may occur due to thread length and plastic shell positioning. ● Needle assembly changeover: 3 minutes; tube assembly changeover: 3 minutes; claw assembly changeover: 9 minutes. ● High production efficiency, saving 2-5 people and reducing manual labor intensity. ● High equipment compatibility; can achieve threading of various rubber sleeves through changeover, changeover time 15 minutes. ● High safety performance; multi-step, two-hand start-up. ● One-button switching between single and two rubber sleeve functions (customizable).
