Product Description Automatic flat cable and hook up wire pressure terminal machine wire terminal crimping machine tin plated machine Product Name TR-DS04 Fully automatic Double-headed tin dipping machine terminal crimping machine Crimping Machine Size 1920x1520x1750(mm) Equipment weight 550KG Working pressure 0.4-0.6Mpa, dry Working voltage AC220V 50HZ Rated current 15A Placement environment The ground is flat and firm, dry, without sunlight Die change Die can be changed ApplicationWire Harness making Brand NameTuring crimping machine Cut length30-1000mm; Flat cable 60-1000mm Efficiency900PCS/h (12P cable)/5000-6000pcs/h for wire FunctionTerminal Crimping and dipping Tin KeywordsAutomatic Crimping Machine Maximum P number20P Model NumberTR-DS04 Peeling length1.0-10mm Place of OriginGuangdong;China Pressure2.0T*2 Product nameFlat cable terminal crimping machine with tin plated...
Feature ● Wire cutting, single (or double) end stripping, single (or double) end crimping, single end insertion of heat-shrink tub and heating, single end sleeve inserting machine ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Functions: Wire cutting, single/double-ended stripping, single/double/parallel-ended crimping, single/double/parallel heat-shrink tubing application. ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Equipped with high-precision servo motors for cutting and stripping mechanisms, the system delivers exceptional accuracy and consistency in wire processing operations. The positive and negative screw structure cutting blade ensures precise stripping results, while the robust ductile iron crimping mechanism provides stable crimping height and superior rigidity for reliable terminal connections. ● Featuring an intuitive color touchscreen interface with comprehensive program memory functions, the machine enables rapid product changeover through one-key parameter recall. The modular design allows individual function modules to be activated or deactivated as needed, maximizing production flexibility and equipment utilization across different product lines and manufacturing requirements.
Feature ● Maximum Rubber Sleeve Size: Diameter 30mm, Thickness 20mm, Square 30*30*20mm. ● Production Efficiency: Average 5 seconds/hole, slight differences may occur due to thread length and plastic shell positioning. ● Needle assembly changeover: 3 minutes; tube assembly changeover: 3 minutes; claw assembly changeover: 9 minutes. ● High production efficiency, saving 2-5 people and reducing manual labor intensity. ● High equipment compatibility; can achieve threading of various rubber sleeves through changeover, changeover time 15 minutes. ● High safety performance; multi-step, two-hand start-up. ● One-button switching between single and two rubber sleeve functions (customizable).
