Product Description Double-sided tape EVA foam laminating cutting machine Self-adhesive release paper automatic laminating cutting machine Pdoduct name Automatic unwinding and fitting cutting machine Product model HDK-400ZF Power supply 220V 50/60Hz Cutting length(mm) 0.1-99999.9mm Cutting speed 30-160pcs/min Feeding width 1-400mm Cutting precision 0.1mm Weight 110kg Size (L×W×H) 910*690*990mm Feeding motor Stepper motor Cutter motor AC motor Cutter material High-speed steel Features 1. All kinds of film, cloth, paper and other roll materials can be cut. 2. The adjustable speed motor cooperates with the photoelectric sensor to realize automatic unwinding and synchronous cutting, with faster speed, higher efficiency and more accurate precision.3. The machine adopts compact design, smaller volume, and is equipped with all-in-one foot cup casters, which can be moved and installed at any...
Feature ● Wire cutting, single (or double) end stripping, single (or double) end crimping, single end insertion of heat-shrink tub and heating, single end sleeve inserting machine ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Functions: Wire cutting, single/double-ended stripping, single/double/parallel-ended crimping, single/double/parallel heat-shrink tubing application. ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Equipped with high-precision servo motors for cutting and stripping mechanisms, the system delivers exceptional accuracy and consistency in wire processing operations. The positive and negative screw structure cutting blade ensures precise stripping results, while the robust ductile iron crimping mechanism provides stable crimping height and superior rigidity for reliable terminal connections. ● Featuring an intuitive color touchscreen interface with comprehensive program memory functions, the machine enables rapid product changeover through one-key parameter recall. The modular design allows individual function modules to be activated or deactivated as needed, maximizing production flexibility and equipment utilization across different product lines and manufacturing requirements.
Feature ● Maximum Rubber Sleeve Size: Diameter 30mm, Thickness 20mm, Square 30*30*20mm. ● Production Efficiency: Average 5 seconds/hole, slight differences may occur due to thread length and plastic shell positioning. ● Needle assembly changeover: 3 minutes; tube assembly changeover: 3 minutes; claw assembly changeover: 9 minutes. ● High production efficiency, saving 2-5 people and reducing manual labor intensity. ● High equipment compatibility; can achieve threading of various rubber sleeves through changeover, changeover time 15 minutes. ● High safety performance; multi-step, two-hand start-up. ● One-button switching between single and two rubber sleeve functions (customizable).
