Product Description Details Images Specification itemvaluePlace of OriginChinaGuangdongBrand NamexinchuangxinModel NumberXCX-680LUsageMultifunctionalNameStripping MachineFunctionpeeling and cuttingWeight30/35/45Size40*30*33Cutting length1-99999.99mmHead peeling length200tail stripping length80/100cutting core0.1-6/10/16mm2Cutting ToleranceAdjustableCapacity3000-5000psc/h Brand Namexinchuangxin Capacity3000-5000psc/h cutting core0.1-6/10/16mm2 Cutting length1-99999.99mm Cutting toleranceAdjustable Functionpeeling and cutting Head peeling length200 NameStripping Machine Place of OriginGuangdong;China Size40*30*33 tail stripping length80/100 UsageMultifunctional Weight30/35/45 Write a review Your Name Your Review Note: HTML is not translated! Rating Bad Good Enter the code in the box below Submit jQuery(document).ready(function($) {...
Feature ● Wire cutting, single (or double) end stripping, single (or double) end crimping, single end insertion of heat-shrink tub and heating, single end sleeve inserting machine ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Functions: Wire cutting, single/double-ended stripping, single/double/parallel-ended crimping, single/double/parallel heat-shrink tubing application. ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Equipped with high-precision servo motors for cutting and stripping mechanisms, the system delivers exceptional accuracy and consistency in wire processing operations. The positive and negative screw structure cutting blade ensures precise stripping results, while the robust ductile iron crimping mechanism provides stable crimping height and superior rigidity for reliable terminal connections. ● Featuring an intuitive color touchscreen interface with comprehensive program memory functions, the machine enables rapid product changeover through one-key parameter recall. The modular design allows individual function modules to be activated or deactivated as needed, maximizing production flexibility and equipment utilization across different product lines and manufacturing requirements.
Feature ● Maximum Rubber Sleeve Size: Diameter 30mm, Thickness 20mm, Square 30*30*20mm. ● Production Efficiency: Average 5 seconds/hole, slight differences may occur due to thread length and plastic shell positioning. ● Needle assembly changeover: 3 minutes; tube assembly changeover: 3 minutes; claw assembly changeover: 9 minutes. ● High production efficiency, saving 2-5 people and reducing manual labor intensity. ● High equipment compatibility; can achieve threading of various rubber sleeves through changeover, changeover time 15 minutes. ● High safety performance; multi-step, two-hand start-up. ● One-button switching between single and two rubber sleeve functions (customizable).
