CNC 3018 Pro Max DIY Engraving Machine 5.5W 10W 15W Laser Engraver 3-Axis GRBL Milling Wood Router PCB PVC Mini CNC3018SpecificationMachine size：374*480*310mmwork plan：300*180*85mmworking desk size：300*180Spindle motor：36WMaximum engraving speed：500-1500mm/minMaximum idle speed：1500mm/mintransfer method：T8 screwSpindle speed：10000rpmMotor drive mode：42 type 1.5A two-phase stepper motorTool diameter：φ3.175mm φ4mm φ6mmOverall material：Aluminum profile table topRails and sliders：Linear circular rail, linear bearingControl System：GRBLProcessing instructions：G code/TAB file/NC file/NCC fileIntroductionDesigned for the absolute beginner, it's a great tool for starting CNC learning. If you are a wood-working amateur, you can use it to add features like curved words and exquisite patterns. If you are a student just start learning CNC, it can help you engrave the models you are coding and...
Feature ● Wire cutting, single (or double) end stripping, single (or double) end crimping, single end insertion of heat-shrink tub and heating, single end sleeve inserting machine ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Functions: Wire cutting, single/double-ended stripping, single/double/parallel-ended crimping, single/double/parallel heat-shrink tubing application. ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Equipped with high-precision servo motors for cutting and stripping mechanisms, the system delivers exceptional accuracy and consistency in wire processing operations. The positive and negative screw structure cutting blade ensures precise stripping results, while the robust ductile iron crimping mechanism provides stable crimping height and superior rigidity for reliable terminal connections. ● Featuring an intuitive color touchscreen interface with comprehensive program memory functions, the machine enables rapid product changeover through one-key parameter recall. The modular design allows individual function modules to be activated or deactivated as needed, maximizing production flexibility and equipment utilization across different product lines and manufacturing requirements.
Feature ● Maximum Rubber Sleeve Size: Diameter 30mm, Thickness 20mm, Square 30*30*20mm. ● Production Efficiency: Average 5 seconds/hole, slight differences may occur due to thread length and plastic shell positioning. ● Needle assembly changeover: 3 minutes; tube assembly changeover: 3 minutes; claw assembly changeover: 9 minutes. ● High production efficiency, saving 2-5 people and reducing manual labor intensity. ● High equipment compatibility; can achieve threading of various rubber sleeves through changeover, changeover time 15 minutes. ● High safety performance; multi-step, two-hand start-up. ● One-button switching between single and two rubber sleeve functions (customizable).
