LK-T6 Hot Air BGA Rework Station 3 Temperature Heating Zones Soldering Welding Machine with Vacuum Suction Pen XBOX-360 RepairParametersDimensions: 690*550*480mmPower supply: 220V 50/60HZEffective power: 3200WMachine weight: 42KGNozzles: 4pcs (42*42mm, 36*36mm; 28*28mm; 23*23mm)Pre-heating size: Max 450*550mmHeating zones: 3 zonesHeating: Hot AirBottom hot air heating: 800WBottom infrared heating: 2800WUpper hot air heating: 800WPerformance indicators and specificationsThis rework station is suitable for repairing circuit boards such as notebook computer motherboards, desktop computer motherboards, and XBOX-360.A total of three temperature zones are independently heated, the upper part is heated by 1000W of hot air, the lower part is heated by 1000W, and the lower part is preheated by 3200W infrared heating.Using touch screen as man-machine interface, PLC precise control, real-time...
Feature ● Wire cutting, single (or double) end stripping, single (or double) end crimping, single end insertion of heat-shrink tub and heating, single end sleeve inserting machine ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Functions: Wire cutting, single/double-ended stripping, single/double/parallel-ended crimping, single/double/parallel heat-shrink tubing application. ● The entire machine supports customisation across multiple aspects, including cutting and stripping lengths. ● Optional crimping force monitor equipment（CFM） and visual inspection equipment
Feature ● Equipped with high-precision servo motors for cutting and stripping mechanisms, the system delivers exceptional accuracy and consistency in wire processing operations. The positive and negative screw structure cutting blade ensures precise stripping results, while the robust ductile iron crimping mechanism provides stable crimping height and superior rigidity for reliable terminal connections. ● Featuring an intuitive color touchscreen interface with comprehensive program memory functions, the machine enables rapid product changeover through one-key parameter recall. The modular design allows individual function modules to be activated or deactivated as needed, maximizing production flexibility and equipment utilization across different product lines and manufacturing requirements.
Feature ● Maximum Rubber Sleeve Size: Diameter 30mm, Thickness 20mm, Square 30*30*20mm. ● Production Efficiency: Average 5 seconds/hole, slight differences may occur due to thread length and plastic shell positioning. ● Needle assembly changeover: 3 minutes; tube assembly changeover: 3 minutes; claw assembly changeover: 9 minutes. ● High production efficiency, saving 2-5 people and reducing manual labor intensity. ● High equipment compatibility; can achieve threading of various rubber sleeves through changeover, changeover time 15 minutes. ● High safety performance; multi-step, two-hand start-up. ● One-button switching between single and two rubber sleeve functions (customizable).
